Basic Specifications
Printing Technology:
- Technology: Serial Inkjet PrecisionCore TFP® with Nozzle Verification Technology
- Colour: Four-colour printing, individual ink cartridge (UltraChrome™ DL pigment ink: C, M, Y, K)
Print Speeds:
Matte Paper Label, Synthetic Label:
- Max Speed (300 x 600 dpi): 119mm/s
- Speed (600 x 600 dpi): 75mm/s
- Normal (600 x 600 dpi): 48mm/s
- Quality (600 x 1200 dpi): 18mm/s
When printing 101.6mm width
Glossy Paper Label, Glossy Film Label, High Glossy Paper Label:
- Normal (600 x 600 dpi): 48mm/s
- Quality (600 x 1200 dpi): 18mm/s
- Max Quality (1200 x 1200 dpi): 8mm/s
When printing 101.6mm width
Ink Cartridge:
- Colours: Black, Cyan, Magenta, Yellow
- Model:
- Black: SJIC40P-BK
- Cyan: SJIC40P-C
- Magenta: SJIC40P-M
- Yellow: SJIC40P-Y
Printing:
- Print Resolution: 1200 x 1200 dpi (max.)
- Max. Print Width: 108mm
Warranty
1-year warranty
Detailed Specifications
Connectivity:
- Interface: USB 2.0, Ethernet 1000Base-T / 100Base-TX / 10Base-T
- Extended Interface: D-sub 25-pin
Print Fonts:
- Built-in Font: Available
- Barcode Font (Printer Driver Built-in):
- Barcode: UPC-A, UPC-E, JAN13 (EAN), JAN8 (EAN), Code39, ITF, Codabar, Code93, Code128, GS1-128, GS1 DataBar (Omnidirectional, Truncated, Limited, Expanded)
- Two-Dimensional Code: PDF417, QR Code, Maxi Code, GS1 DataBar Stacked (Omnidirectional, Expanded Stacked), DataMatrix, Aztec Code, MicroPDF417, Micro QR Code
Media Handling:
- Media Source: Roll media, Fanfold
- Media Type: Matte paper label, Synthetic label, Glossy paper label, Glossy film label, High glossy paper label
- Media Form:
- Roll: Continuous label (BM or without BM), Die-cut label (Gap or BM)
- Fanfold: Die-cut label (BM)
Paper Specifications:
- Paper Core External Diameter: 82.2mm or more
- Number of Folds: 750 or less
- Winding Direction: Face Out
Auto Cutter Life:
- Die-cut Label:
- Matte paper, Glossy paper, Glossy film, High glossy paper: 1,500,000 cuts
- Synthetic: 500,000 cuts
- Continuous Label:
- Glossy paper: 300,000 cuts
- Matte paper, High glossy paper: 200,000 cuts
- Synthetic, Glossy film: 100,000 cuts
Temperature / Humidity:
- Printing: 5 to 35°C / 20 to 80% RH
- Barcode Printing: 15 to 35°C / 20 to 80% RH
- Storage (when packed, ink not charged): -20 to 60°C / 5 to 85% RH (no condensation)
Dimensions & Weight:
- Overall Dimensions (W x D x H): 340 x 565 x 326mm (excluding protrusions)
- Mass: Approx. 22.5kg
Power Supply & Consumption:
- Power Supply: Built-in
- Operating Power Consumption:
- 100V: Approx. 39.4W
- 230V: Approx. 38.6W
- Standby Power Consumption:
- 100V: Approx. 7.51W
- 230V: Approx. 5.82W
- Power Off Consumption:
- 100V: Approx. 0.08W
- 230V: Approx. 0.24W
- Rated Voltage: 100 – 240VAC
- Rated Frequency: 50 – 60Hz
Compliance & Operating System:
- EMC Standards:
- Europe: CE Marking
- North America: FCC Class A, CAN ICES-3 (A) / NMB-3 (A)
- Oceania: Radiocommunications (Electromagnetic Compatibility) Standard, Class A
- Operating System Support:
- Windows: 10, 8.1, 8, 7 SP1, Vista SP2, XP SP3 or later, Server 2019, 2016, 2012 R2, 2012, 2008 R2, 2008, 2003 R2 (32-bit)
- Mac OS: X 10.6.8 to 10.14.x
Printer Details:
- Options: Paper Holder C6000 (for C6050 Series)
- Media Handling:
- Width:
- Backing Paper Width: 25.4 to 112mm
- Label Width: 21.4 to 108mm
- Thickness:
- Matte Paper Label: 0.178mm
- Synthetic Label: 0.235mm
- Glossy Paper Label: 0.174mm
- Glossy Film Label: 0.164mm
- High Glossy Paper Label: 0.188mm
- Roll Diameter (Max): 203.2mm
- Core Diameter (Inner): 76.2mm ± 0.5mm
- Die-cut Label Gap: 2 to 6mm (if 3mm or less, detector adjustment required)
- Black Mark Size:
- Width: 18.4mm or more
- Length: 4 to 25.4mm
- Width:
